Blades

Curved sinus blades

<p>Curved&nbsp;sinus blades&nbsp;offer a range of sizes and degrees of curvature&nbsp;for&nbsp;microdebrider-assisted sinus procedures.</p>

Ordering information
Contact a representative

Curved sinus blades — Rotatable​

Rad Navigation

RAD™ / 12° Blades

  • 11.0 cm long with curved shaft​
  • 3.5 mm - 4.0 mm diameter

  • StraightShot™ M5 rotates blade tip 360° without shaft rotation​

  • Offset cutting surface cuts in 3 planes​

  • Application: uncinectomy, ethmoidectomy​

  • Operating speed: up to 7,500 rpm†, oscillate​

Rad Navigation

RAD / 40° Blades​

  • 11.0 cm long with curved shaft​
  • 3.5 mm - 4.0 mm diameter

  • StraightShot M5 rotates blade tip 360° without shaft rotation​

  • Offset cutting surface cuts in 3 planes​

  • Application: uncinectomy, ethmoidectomy​

  • Operating speed: up to 7,500 rpm†, oscillate​

Rad Navigation

RAD / 60° Blades​

  • 11.0 cm long with curved shaft​
  • 3.5 mm - 4.0 mm diameter

  • StraightShot™ M5 rotates blade tip 360° without shaft rotation​

  • Offset cutting surface cuts in 3 planes​

  • Application: uncinectomy, ethmoidectomy​

  • Operating speed: up to 5,000 rpm†, oscillate​

Rad Navigation

RAD / 90° Blade​

  • 11.0 cm long with curved shaft​

  • 3.5 mm diameter
  • StraightShot M5 rotates blade tip 360° without shaft rotation​

  • Offset cutting surface cuts in 3 planes​

  • Application: maxillary polypectomy, frontal sinusotomy​

  • Operating speed: 2,000-3,000 rpm†, oscillate​

Curved sinus blades — Non-rotatable​

Rad non rotatable

RAD / 60° Blade​

  • 11.0 cm long with curved shaft​
  • 2.9 mm diameter
  • Offset cutting surface cuts in 3 planes​

  • Same inner lumen as wider 3.5 mm blades​

  • Application: frontal sinus surgery​

  • Operating speed: 1,500 rpm†, oscillate​

    •

Rad non rotatable

RAD / 120° Blade​



  • 11.0 cm long with curved shaft​
  • 3.5 mm diameter

  • Tapered tip to allow maximum bend angle

  • Application: maxillary polypectomy​

  • Operating speed: 1,500-3,000 rpm†, oscillate​

  • 3 each, irrigation tubing separate​

† Speeds are suggested revolutions per minute (rpm), operated in oscillation mode for blades and forward mode for burs.

Ordering information

CFN Blade Name Diameter  Length  Angle  Rotation Quantity
1883512HRE 3.5 mm RAD™ 12 blade 3.5 mm 11.0 cm 12° curved Rotatable 1 each
1884012HR 4.0 mm RAD™ 12 blade 4.0 mm 11.0 cm 12° curved Rotatable 5 each
1883517 4.0 mm RAD™ 120 blades 3.5 mm 11.0 cm 120° curved Non-rotatable 3 each
1884006HR 4.0 mm RAD™ 40 blades 4.0 mm 11.0 cm 40° curved Rotatable 5 each
1883506HRE 3.5 mm RAD™ 40 blades 3.5 mm 11.0 cm 40° curved Rotatable 1 each
1882916 2.9 mm RAD™ 60 blades 2.9 mm 11.0 cm 60° curved Non-rotatable 3 each
1883516HRE 3.5 mm RAD™ 60 blade 3.5 mm 11.0 cm 60° curved Rotatable 1 each
1884016HR 4.0 mm RAD™ 60 blade 4.0 mm 11.0 cm 60° curved Rotatable 5 each
1883519HR 3.5 mm RAD™ 90 blades 3.5 mm 11.0 cm 90° curved Rotatable 3 each
