Cardiovascular guidewires

F-14™* and F-18™* peripheral guidewires

<p>F-14™* and F-18™* stainless steel guidewires are available in multiple tip loads, two lengths, and are engineered for routine to complex interventions.</p>

Ordering information

Contact a representative

Indications, Safety, and WarningsIndications (or Intended Use)FMD Peripheral Guide Wires are intended to facilitate the placement and exchange of diagnostic and therapeutic devices during intravascular procedures. This device is intended for peripheral use only.ContraindicationsThis guide wire is not intended for use in coronary or cerebral vasculatures and not intended for use with atherectomy devices.Potential Adverse Events (or Potential Complications)Possible complications and adverse events of guide wire use include, but are not limited to: Access site complications, Allergic reaction (to contrast, device or other), Aneurysm, Angina or unstable angina, Bleeding / hemorrhage, Bradycardia / Palpitation, Cardiac tamponade / pericardial effusion, Death, Embolization (plaque, thrombus, device, tissue, or other), Fistula of artery or vein, Hypotension / Hypertension, Infection, Myocardial infarction or ischemia, Separation or breakage of the guide wire, Stroke / cerebral vascular accident (CVA) / transient ischemic attack (TIA), Thrombosis / Thrombus, Vasospasm, Vessel trauma / perforation / dissection, X-Ray radiation exposure complications (e.g., alopecia, burns ranging in severity from skin reddening to ulcers, cataracts, and delayed neoplasia).CAUTION: Federal (USA) law restricts this device to sale by or on the order of a physician. Important Information: Indications, contraindications, warnings and instructions for use can be found in the product labeling supplied with each device.UC202501855 EN

Features

Radial access

The F-18™* series includes the first 0.018" 400 cm wire in the United States, giving physicians the option to treat via radial access.

Versatility

0.014" and 0.018" diameters
Treat above and below the knee
300 cm and 400 cm lengths

Design features

Multiple tip loads to navigate tortuous vessels and cross challenging lesions or occlusions
Shapeable distal tip
Radiopaque covering ensures accurate positioning
The tapered wires include a low profile tip to cross challenging lesions
Stainless steel core provides strength and torqueability
The core shaft is coated with polytetrafluoroethylene (PTFE) for consistent and smooth crossing
Hydrophilic coating provides lubricity to reduce friction, improve ease of navigation, and smooth advancement for good trackability

Hydrophilic coating
Polymer jacket
Radiopaque distal tip
PTFE coating

F-14™* Flex guidewire

This is an illustration of the F-14™* peripheral guidewire with numbered callouts.

F-18™* Floppy guidewire

This is an illustration of one of the F-18™* peripheral guidewires with numbered callouts.

View guidewire specs (open in new window)

From routine to complex

The F-14™* and F-18™* guidewire series provides the versatility needed to treat a broad range of cases. As the complexity increases, choose a guidewire with a higher tip load.

View this graph to see how lesion complexity increases with lesion penetration for the F-14™* and F-18™* peripheral guidewires.

Guide-to-wire selection

Each patient is unique, and every physician has their preferred technique, but you may find this grid helpful in guidewire selection.

Above the knee

F-14™* Tapered 15
F-14™* Tapered 30
F-18™* Flex
F-18™* Floppy
F-18™* Hard 15

Below the knee

F-14™* Gentle
F-14™* Light floppy
F-14™* Flex
F-14™* Tapered 3
F-14™* Tapered 15
F-14™* Tapered 30

Ordering information

F-14™* series

Model number	Diameter	Type	Tip load (gf)	Length (cm)	Shaft coating	Distal coating	Units per package
F14G01ST300	0.014"	Gentle	1	300	PTFE	Hydrophilic and polymer jacket	5
F14L02ST300	0.014"	Light	2	300	PTFE	Hydrophilic and polymer jacket	5
F14F03ST300	0.014"	Flex	3	300	PTFE	Hydrophilic and polymer jacket	5
F14T03ST300	0.014"	Tapered	3	300	PTFE	Hydrophilic	5
F14T15ST300	0.014"	Tapered	15	300	PTFE	Hydrophilic	5
F14T30ST300	0.014"	Tapered	30	300	PTFE	Hydrophilic	5

F-18™* series

Model number	Diameter	Type	Tip load (gf)	Length (cm)	Shaft coating	Distal coating	Units per package
F18F04ST300	0.018"	Flex	4	300	PTFE	Hydrophilic and polymer jacket	5
F18P06ST300	0.018"	Floppy	6	300	PTFE	Hydrophilic	5
F18H15ST300	0.018"	Hard	15	300	PTFE	Hydrophilic	5
F18F04ST400	0.018"	Flex	4	400	PTFE	Hydrophilic and polymer jacket	5

Resources

View the F-14™* and F-18™* peripheral guidewire brochure.

F-14™* and F-18™* Guidewires Product Brochure (open in new window)

Share for an overview of design features, tip loads, and sizing of the FMD F-14™* and F-18™* peripheral guidewires.

PRODUCT PDF 749 KB

Crossing Portfolio Brochure (open in new window)

Share this robust crossing portfolio toolkit to help you confidently navigate tortuous vasculature and cross complex lesions.

PRODUCT PDF 851 KB

Wall Chart (open in new window)

View specs for the F-14™* and F-18™* guidewires, available in multiple tip loads and two lengths.

PRODUCT PDF 408 KB

View the radial access portfolio info sheet to learn about devices that can be used to treat PAD from a radial approach.

Radial Access: Your Choice Info Sheet (open in new window)

Share this one-pager about the products physicians can use to treat PAD via radial access, including the 200 cm IN.PACT™ 018 DCB, the 200 cm Pacific™ Plus PTA catheter, and 400 cm F-18™* peripheral guidewire.

PRODUCT PDF 552 KB
